Lazer - Triple-R 750 - Gen 2 (with Pos Light)

Name: Lazer - Triple-R 750 - Gen 2 (with Pos Light)
Price: 258 GBP
Availability: InStock

£258.00

Quantity

Only 4 left in stock

The iconic Triple-R range, upgraded in 2020/21, delivers exceptional, long-range auxiliary LED automotive lighting. Initially developed for the uncompromising requirements of professional track and rally motorsport, the range has evolved to become a firm favourite across the passenger car, 4x4, light commercial, and heavy truck market, both on and off-road. Recent additions to the Triple-R range boast innovative features and functionality, including patent-pending technology never seen before in an auxiliary LED light bar.

Available in a variety of sizes from the 230mm (9”) Triple-R 750 to the 1305mm (51”) Triple-R 28 Elite, all Triple-R products up to the 590mm (23”) Triple-R 1250, benefit for approval to UNECE Regulation 112 as a high beam driving light. In many cases certification is only achieved using dual-output E-Boost technology, allowing the lamp to be used in both E-Boost or E-Mark Compliant mode depending on country-specific regulations and whether the light(s) are being used on or off-road.

Like all Lazer high performance lights, the Triple-R range is designed, engineered, and built in-house, in our UK premises, you can be fully assured of exceptional high-end product design, coupled with superior levels of illumination, all backed up by our comprehensive 5-year warranty.

What's included: - x1 Triple-R 750 LED Lamp - x1 Centre Mount (1114k) - x1 Installation Instructions

Features:

Highly efficient 11W LED technology (upgraded for 2020/21)

5000K LED colour temperature and 80CRI maximises sharpness and definition

Integrated white and amber position light function

Ultra-reflective vacuum-metallised optics deliver spot beam pattern

UNECE Reg 112 Class B Driving Light, approved for on-road high beam (E-Boost technology) and Reg 7 position/side light function (white only)

Contemporary lamp design

Includes versatile ‘Centre Mount’ mounting system plus integral features to enable side mounting (brackets sold separately)

Electronic thermal management system optimises light output to preserve longevity of the LEDs

Anodised pre-treatment and automotive grade powder top-coat for ultimate corrosion and chemical protection

CAE optimised heatsink offers improved thermal dynamics

Over voltage protected

Reverse polarity protected

‘Unbreakable’ polycarbonate lens with hardcoat lacquer

UNECE approved Reg 10

IP67 watertight

5-year warranty

Supplied with pre-wired male/female 3-pin Superseal connectors

Designed & manufactured in UK

Voltage Range (DC)	10-32V
LED Life	50,000 hours
Weight	1 kg
HIGH BEAM FUNCTION
Total Luminous Flux	4620 Lm
Total Driver 'FOV' Flux †	2786 Lm
Colour Temperature	5000k
Number of High Output LEDs	4
Power Consumption	45 Watts
Current Draw (at 14.4V)	3.1 Amps
Start-Up Time *	100ms
CERTIFICATION
High Beam	ECE R112
E-Mark Ref	35
Position Light (White)	ECE R7
PHOTOMETRIC DATA
Horiz Beam Angle	19 Deg
0.25 lx Line	866 metres
0.5 lx Line	612 metres
1 lx Line	433 metres
3 lx Line	250 metres

*'Start-up time' is the delay between the lamp receiving voltage, and light being emitted. Different Lazer lamps have different start-up times, depending on their electrical architecture, so we recommend that if you are buying two different types of Lazer lamp, for mounting on to the same vehicle, that you ensure you pick products with matching start-up time (either 5ms or 100ms, depending on the product). Please check the lamps technical section on each product page to be sure you are purchasing lights with the same start-up time for the best performance.

† Driver FOV flux is a measure of effective lumens taking consideration of the amount of light in a driver's 'field-of-view' defined as an area +/- 45o left/right, and +/- 10o up/down.
